- During analog to digital conversion with PIC the noise occurs
- The problem is current from the supply because it does not absorb enough the noise ,We have developed a circuit for it (together with my brother) ;-)
- Circuit transformer, capacitor and diode is comprised of. Operating logic, capacitors absorb noise.
- Three output transformer should be selected. Because the output (+9v) (GND) (-9v)
- IMPORTANT! – Works with PIC s 5v circuit voltage of 5 volts should regulate, or PIC will be damage!!!.(9v>5v regulator circuit)
Required Materials
- 1 PCS – 130 mm x 60 mm Pertinaks
- 1 PCS – 2s Tunic Socket (220V for input)
- 1 PCS – Button (220v for open-close )
- 1 PCS – 9v transformer (Three output transformer should be selected)
- 1 PCS – B500C2300 Bridge Diode
- 2 PCS – 1000uf electrolytic capacitor (50V)
- 2 PCS – 100 nf polyester Capacitors
- 1 PCS – 3k3 resistor
- 1 PCS – LED
- 3 PCS – Precision socket or other socket
Circuit Schematic
Technical Documents
